Radiator
Dimentions/mm 277*120*27
Block Material Copper
Radiator Material Aluminum
Tube Material Low Evaporation Rubber
Fan
Dimentions/mm 120*120*22
Rated Speed.PWM 800~1900 RPM(PWM) +/- 10%
Air Flow 58.8 CFM
Fan Noise 28.8dBA
Fan Type PWM ARGB LED Fan
Connector 4pin PWM for fan power+3pin 5V ARGB Header
Rated Voltage DC 12V
Fan Pressure 2.2mm H2O
Life 30,000 hours
Pump
Block Compatibility Intel LGA 2066/2011V3/2011/115X/1200
AMD AM4/AM3+/AM3/FM2+/FM2
Dimentions/mm 80.3*71*47
RPM 2500+/- 10%
Input Voltage DC 12V
Noise 30dBA(Max)
Water Pressure 1.2m
Flow Rate >1300ML/min
